Page 223 - Custom Chrome Catalog

CHASSIS
80203001 80203002 80204001 80204002

80203001 Fits '18-later FXBB and $99.50 80204001 Fits for breakout 13-17 $219.99
FXLR, '20-Later FXLRS, FXSB ,18-later FXBR;wide
FXST and '21-later FXBBS glide FXDWG 06-17 (repl.
models. Requires separate OEM: 58387-060)
purchase of model specific 80204002 Fits for '18-later FXBB, $219.99
bracket kit.
FXLR, '14-'17 FXDL, '20-
80203002 Fits '18-later FXBB,FXLR and $49.99 later FXST and '21-later
FXST. FXBB and FXST FXBBS models. Does not
installation requires fit FXLRS (repl. OEM:
separate purchase of 57400331)
12700164, 67800630 &
67015-02 (2). FXLR models 80204003 Fits '06-'17 Dyna® (except $219.99
with Tall Risers/Moto Bars 80203003 80203004 80204003 80204004 FLD, FXDWG, FXDF and
FXDSE) and '18-later
require separate purchase of FXBB, '20-later FXST and
12700164, 67800630 & '21-later FXBBS models.
67015-02 (2) (repl. OEM: FXDLS models require the
57001249)
removal of Original
80203003 Fits for 06-17 Dyna; 99-05 $29.99 Equipment Wind
Dyna with the 39mm fork Deflector repl. OEM:
clamps (Professional 58346-06)
installation recommended);
00-03 T-Sport (Direct for 4 80204004 Fits '18-later FLFB and $219.99
FXDXT T-sport only); 87-99 FLFBS models; Fat Boy
FXR FLFB 18-20; Fat Boy 114
FLFBS 18-22 (repl. OEM:
80203004 Fits for Dyna Low Rider $999.99 57400367)
FXDL/I 06-09, 16-17; Dyna
Street Bob FXDB/I 06-17; 80204005 Fits '88-'22 XL (except $149.99
Dyna Super Glide Custom XL1200CX, XL1200T,
FXDC/I 06-14; Dyna Super 80203005 80203006 80204005 80204006 XL1200X, XL1200XS,
Glide FXD/I 06-10; Dyna XR1200, XR1200X and '11-
Wide Glide FXDWG/I 06-17 later XL883L and XL1200C).
XL1200NS requires removal
80203005 Fits for 22-24 Low Rider ST $89.99 of headlight visor. Also fits
FXLRST; 22 Low Rider El '91-'05 Dyna models
Diablo FXRST (repl. OEM: 4 (except FXDWG and
67700629/61400758) FXDXT) (repl. OEM: 58602-
80203006 Fits for Harley Low Rider ST $99.99 04)
FXLRST 22-24; Harley Low 80204006 Fits for Harley Dyna & $29.99
Rider El Diablo FXRST 22 CHASSIS Sportster Models With
80203007 Fits for 22-24 Low Rider ST $799.99 39mm Forks (repl. OEM:
FXLRST; 22 Low Rider El 57400536/57400006/5817
Diablo FXRST 4-04A)
80040060 Fits for Harley Low Rider $599.99 80204007 Fits for Harley Dyna & $29.99
ST FXLRST 22-24 / Low Sportster Models With
Rider El Diablo FXRST 22 80203007 80040060 80204007 80204008 39mm Forks (repl. OEM:
(Direct fit) Harley Low 57400536/57400006/5817
Rider S FXLRS 20-24 / Low 4-04A)
Rider FXLR 18-20 (Requires 80204008 Fits for 93-05 FXDWG and $39.99
Docking Hardware Kit '88-'13 FXS, FXST, FXSTB
67801349 and rear turn and FXSTC models (repl.
light removal)
OEM: 57400007)
80040061 Fit for Harley Sport Glide $599.99 80204009 Fits for 93-05 FXDWG and $39.99
FLSB 18-24; Harley Street '88-'13 FXS, FXST, FXSTB
Bob 18-24; Harley Softail and FXSTC models (repl.
Standsrd 18-24 OEM: 57400007)
80204010 Fit for '02-'10 VRSCA and $49.99
VRSCAW, '04-'05 VRSCB,
'07 VRSCX, '16-later
XL1200X, '06-'17 Dyna
80040061 80204009 80204010 (except FLD) and '18-later
FXBB, FXBR, FXBRS and
FXLR models equipped
with Quick-Release style
windshields (repl. OEM:
57400008)
80204011 Fit for '02-'10 VRSCA and $49.99
VRSCAW, '04-'05 VRSCB,
'07 VRSCX, '16-later
XL1200X, '06-'17 Dyna
(except FLD) and '18-later
FXBB, FXBR, FXBRS and
FXLR models equipped
with Quick-Release style
windshields (repl. OEM:
Color(s) on photo might be slightly different, please refer to the actual products. All pictures shown are Color(s) on photo might be slightly different, please refer to the actual products. All pictures shown are 57400008)
for reference only. Please consult your dealer for fitment. for reference only. Please consult your dealer for fitment.

www.customchrome.com 4.22 4.23 *Prices shown are suggested retail prices only. Actual retail prices are determined by each dealer and may vary. Please see Cautionary Information in back of catalog.
All parts are sold each unless otherwise noted. Retail prices may reflect an each quantity.
