Page 282 - Custom Chrome Catalog

CHASSIS
15232 15233 12263

Chrome Fork Tube Caps Chrome Frame Cups, Bearings
15232 Chrome fork tube caps $20.99 and Bearing Races
for Sportster, FX and FXR For Big Twin Models
models with fine threads 12263 Timken-style chrome cups $26.99
from 73-86 (replaces with races ONLY for Big
OEM 45993-73) sold in Twins (except Springer
pairs Softail models) from 60-88
15233 Chrome fork tube caps $19.99 (repl. OEM 48311-60) set
for FL models from 49- of 2. Also fits 49-59 Big
E77 (replaces OEM Twins when CC #12264
45754-60) sold in pairs bearings are used
12264 Replacement Timken $9.99
13009 160111 12253 bearing ONLY for Big Twins
Chrome Fork Stem Nut Covers from 60-13 (sold each)
These covers are held in place on the stock 26135 Replacement races ONLY $10.99
stem nuts by a set screw, and fit most 39 mm for Big Twins 60-13 (repl.
and 41 mm forks from 80-03. OEM 48315-60) set of 2
13009 Fits 39 mm forks on FXR $10.99 For Sportster Models
models from 87-00 as 17381 Custom Timken bearing $60.99
well as Sportster models conversion kit for all
from 88-03 (repl. OEM Sportster and K models
48329-90) from 54-77. Includes
160110 Fits FXWG and FXST $7.99 chrome cups and bearings
models from 80-99 (repl. 13089 Replacement upper Timken $19.99
OEM 45670-80) bearing only for CC #17381
conversion kit (sold each)
13098 Replacement lower Timken $24.99
Triple Tree Nut Cover Sets bearing ONLY for CC #17381
09652 09625 12264
Three-piece kit includes: chrome covers for conversion kit (sold each)
fork tube caps and triple tree stem nut. 13099 Replacement Timken $68.99
Attach with set screws. bearing ONLY for Sportster
160111 Fit Softail and FXWG $26.99 models 78-81 (sold each)
models from 80-99 4 12264 Replacement Timken bearing $9.99
ONLY for Sportster models
Chrome Acorn Stem Nut 26135 from 82-13 (sold each) $10.99
Replacement races ONLY
Functional and good-looking part accents CHASSIS for Big Twins 78-13 (repl.
most front forks. OEM 48315-60) set of 2
09652 Fits most FL, FXWG, FX $12.99 169901 Replacement bearing race $11.99
Softail and Dyna Wide only (sold each - 2 used).
Glide models. (1" x 24 For use with CC #17381
thread) 150999 Replacement chrome $18.99
frame cups only (set of 2).
09626 09627 160003 For use with CC #17381
Replacement Steering Stem Chrome Frame Neck Cup and
Parts Bearing Kit
The most frequently lost or damaged parts on Includes frame cups,races, 2 Timken bearings
the forks of most 49-14 Big Twins. and chrome dust shields.
09625 Bearing Jam nut. Sold $6.99 12253 Fits Big Twins from 49-88 $45.99
each and most custom frames
09626 Replacement chrome $7.99 Neck Bearings and Races
stem nut (sold each)
09627 Stem nut locktab (pack $1.40 12264 Replacement bearing only $9.99
of 10) for Sportster models from
82-13 and Big Twin
160035 Upper nut $7.99
models 60-13 (repl. OEM
48300-60) sold each
160003 Replacement bearing race $6.99
Stem Nut and Lock Washers 160035 500602 160014 160047 25279 only for Sportster models
Fits 4-speed FL models from 49-84, FXWG, from 78-13 and Big Twins
FXST, FXDWG and Touring models from 80-13 60-13 (repl. OEM 48315-60)
(1"-24 thread). sold each
500602 Stem nut and lock $12.99 160047 Sealed bearing* (repl. $35.99
washer kit OEM 48300-60) sold each
*Note: Race and bearing should be replaced at the
160014 Fork stem lockwasher $1.60 same time. Use with CC #160003 bearing race only.
ONLY (repl. OEM 45717-
63) pack of 5 Chrome Dust Shield Set
Upper and lower set for all FL, FXWG, Softail
and FLT/FLHT models from 49-88. Includes the
original style lower cover and 77-88 upper
shield. Set of two.
25279 Replaces OEMs 43865- $4.99
48A, 48361-80
Color(s) on photo might be slightly different, please refer to the actual products. All pictures shown are Color(s) on photo might be slightly different, please refer to the actual products. All pictures shown are
for reference only. Please consult your dealer for fitment. for reference only. Please consult your dealer for fitment.

www.customchrome.com 4.80 4.81 *Prices shown are suggested retail prices only. Actual retail prices are determined by each dealer and may vary. Please see Cautionary Information in back of catalog.
All parts are sold each unless otherwise noted. Retail prices may reflect an each quantity.
