Adjustable Mounting Plates 17138
Mounting plate is CNC-machined for accuracy.
The built-in dual adjusters operate from the end
of the 1/2"-thick steel plate by counterbored
sockethead screws.They permit accurate
alignment of the mainshaft, ideal for open belt
drives. Three holes at the front to fit various
frames. Fits 4-speed Big Twin transmissions from
79-86 with flat bottom cases and 36-E78 if the
sliders are milled off the bottom of the case.
17138 Black $69.99
Note: Will not work with S.T.D. 4-speed cases.

060000
Transmission Mounting Plate TRANSMISSION & DRIVELINE
Steel, chromed, transmission mounting plate
for 4-speed Big Twin models 36-85. Drilled for
both early and late frame tabs.
Note: May interfere with transmission mounted oil filter
bracket on late 82-85 models.
060000 Chromed Steel, mounting $38.16
plate

Transmission Mounting Plate
for Softail Models
Looks great, works great. Chromeplated, black
or raw steel plate will fit all Softail models from 17141 17285
86-99. Replaces OEM 47698-86B.
17141 Chrome transmission $24.99
mounting plate, Replaces
OEM 47698-86B
650141 Black transmission mounting $18.99
plate
650138 Raw transmission mounting $13.99
plate

Offset Transmission Plates
These 1-inch offset mounting plates for 5-speed
Softail transmissions, make assembly of Wide 17286
Drive swingarm or extra wide rigid-framed
customs a snap. The hot set-up for building that
extra-wide ride.
17285 Chrome mounting plate $24.99
17286 Raw steel mounting plate $17.99

1/4" Offset Driveline Kit
In addition to a chrome primary spacer this kit
includes a chrome transmission plate, bolts, O-
rings, sprocket shaft spacer and rear pulley
spacer. Permits the use of 1/2" wider tires in a
stock chassis. 17289 15999
17289 Fits Softail models from 86-99 $89.99

Transmission Adjusting Kit
Permits accurate alignment and adjustment of
the transmission mainshaft. The transmission is
held by the four jam nuts.
15999 Fits 4-speed Big Twins from $28.99
58-86 (except Softail models)

www.customchrome.com 2.15
