Adjustable Mounting Plates 17138
Mounting plate is CNC-machined for
accuracy. The built-in dual adjusters
operate from the end of the 1/2"-thick
steel plate by counterbored sockethead
screws. They permit accurate alignment of
the mainshaft, ideal for open belt drives.
Three holes at the front to fit various
frames. Fits 4-speed Big Twin transmissions
from 79-86 with flat bottom cases and
36-E78 if the sliders are milled off the
bottom of the case.
17138 Black $69.99
Note: Will not work with S.T.D. 4-speed cases. 060000
M17138 TRANSMISSION & DRIVELINE

Transmission Mounting Plate
Steel, chromed, transmission mounting
plate for 4-speed Big Twin models 36-85.
Drilled for both early and late frame tabs.
Note: May interfere with transmission mounted oil filter
bracket on late 82-85 models.
060000 Chromed Steel, $38.16
mounting plate
M060000
Transmission Mounting Plate
for Softail Models
Looks great, works great. Chrome-
plated, black or raw steel plate will fit all 17141 17285
Softail models from 86-99. Replaces OEM
47698-86B.
17141 Chrome transmission $24.99
mounting plate,
Replaces OEM 47698-
86B
650141 Black transmission $18.99
mounting plate
650138 Raw transmission $13.99
mounting plate
M17141
Offset Transmission Plates
These 1-inch offset mounting plates 17286
for 5-speed Softail transmissions, make
assembly of Wide Drive swingarm or extra
wide rigid-framed customs a snap. The hot
set-up for building that extra-wide ride.
17285 Chrome mounting $24.99
plate
17286 Raw steel mounting $17.99
plate
M17285
1/4" Offset Driveline Kit
In addition to a chrome primary spacer this
kit includes a chrome transmission plate,
bolts, O-rings, sprocket shaft spacer and 17289 15999
rear pulley spacer. Permits the use of 1/2"
wider tires in a stock chassis.
17289 Fits Softail models $89.99
from 86-99
M17289
Transmission Adjusting Kit
Permits accurate alignment and adjustment
of the transmission mainshaft. The
transmission is held by the four jam nuts.
15999 Fits 4-speed Big Twins $28.99
from 58-86 (except
Softail models)
M15999
