P. 459
Easy Starter Kits for Big Twin Models
17664
Improves starting on high-compression big inch engines through an
improved starter-to-clutch basket gear ratio. Complete kits include a clutch
basket for Big Twin models with a 66-tooth starter ring and a 9-tooth starter
pinion gear.
17664 Complete kit for Big Twin models from 94-97 $243.99
17665 Complete kit for Big Twin models from 98-06 (except $243.99
06 Dyna)
Replacement Parts
17448 Clutch basket with ring gear for CC #17664 $234.99
17663 Clutch basket with ring gear for CC #17665 $249.99
23185 66-tooth starter ring gear with hardware fits only CC $55.99
#17420 clutch basket and OEM 37707-90
23183 9-tooth pinion gear $22.99
M17664
Starter Ring Gear
Replacement ring gear for the clutch drum. Fits electric start Big Twins
(except diaphragm clutch) from 65-E84.
17402 Replaces OEM 33163-65B $58.99
17402
M17402
Replacement Starter Jackshaft Kits
Complete jackshaft kits include starter shaft, coupling, pinion gear, clips,
spring, locktab, washers and screws.
28380 10-tooth for Big Twins from 94-06 (except 06 Dyna) $89.99
628370 9-tooth for 94-06 Big Twins from when using a $71.37
66-tooth starter ring gear on 94-06 models
28381 9-tooth for Big Twins from 89-93 $89.99
Replacement Starter Motor Parts
Listed below in OEM part number order. All parts are sold each.
28386 Pinion gear for Big Twins from 89-93 (repl. OEM 31342- $23.99
90)
28382 Coupling for Big Twins from 89-93 (repl. OEM 31548- $9.99
90) 28380
28384 Extension shaft for Big Twins from 89-93 (repl. OEM $25.99
33127-90)
688565 Starter shaft bushing 89-93 Big Twins OEM 33445-89 $6.99
688564 Starter shaft bushing 94-06 Big Twins (exc. 06 Dyna) $7.49
OEM 33445-94A
92200 Starter shaft bushing for Big Twins from 89-93 (repl. $5.99
OEM 33445-89)
28383 Pinion coupling for Big Twins from 89-93 (repl. OEM $15.99
60647-90)
M28380 28616
Starter Shaft for Big Twins
28616 Starter shaft ONLY for 4-speed FL chain drive models $24.99
from 70-82, and 4-speed FX chain drive models from LIGHTING, INSTRUMENTS & ELECTRICAL
71-85 (replaces OEM 31482-70)
M28616
Starter Motor Housings
Replacement starter motor housings that duplicate the Original Equipment
parts which commonly have the mounting ears broken off. Needle bearing
not included.
09782 Fits 4-speed Big Twin models with Prestolite motor $44.99 09782
65-E79 (repl. OEM 31465-65) 1/4-20 threads (use CC
#28605 bolts)
09779 Fits 4-speed Big Twin models with Hitachi motor $44.99
73-E79 (repl. OEM 31572-73) 10-24 threads (use CC
#28625 bolts)
09778 Starter housing bearing (replaces OEM 9062) sold $9.99
each
M09782
