Evolution Big Twins
10
21
1 2
9 17
8
23
11
29 31
24
22
16
15
32
14
19 18
13 12
Gaskets for Evolution Big Twins 84-99
No. Replaces Motor Pack Description Each Price
OEM# Factory Qty
Cylinder Gaskets
1 16770-84D 660346 2 Cylinder head, 84-99, .060" thick graphite coated / steel core fire ring $9.00
1 16773-85 660347 2 Cylinder head, 84-99, .048" thick (stock) graphite coated / steel core fire ring $9.00
1 16773-85 54105 10 Cylinder head, 84-99, .043" Teflon $6.00
2 16777-83A 660349 10 Cylinder base, 84-99, Hydro-Fused $1.30
660353 10 Cylinder base, 3 5/8" bore .020", Hydro-Fused $1.00
Rocker Box Gaskets
3 16778-84A 660350 10 Lower rocker cover to cylinder head, right, 84-99, Hydro-Fused $1.40
4 16779-84A 660352 10 Lower rocker cover to cylinder head, left, 84-99, Hydro-Fused $1.90
4A 16800-84A 660320 2 Lower rocker cover one piece (left/right) 84-99, RCS $9.00
5 17355-84 54116 10 Rocker cover, lower (cork), 84-91 $3.00
5 17355-84A 54080 10 Rocker cover, lower (silicone), 84-91 $3.00
5 17355-92 54085 10 Rocker cover, lower (silicone), 84-99 $3.10
6 17356-84 54117 10 Rocker cover, upper (cork), 84-91 $2.90
6 17356-84A 54081 10 Rocker cover, upper (silicone), 84-91 $3.00
6 17356-92 54086 10 Rocker cover, upper (silicone), 92-99 $3.10
7 17358-84 54118 10 Rocker cover, inner (cork), 84-91 $0.50
6 7 - 17358-84A 54082 10 Rocker cover, inner (silicone), 84-99 $1.00
Rocker cover screw, 84-99
$0.30
10
54227
63858-49
Carb / Intake Gaskets
14 29058-77 660368 10 Air cleaner to carburetor, 84-89, Syntheseal $0.50
- 29059-88 660369 10 Air cleaner to CV carburetor, 90-99, Syntheseal $0.50
- 29062-95B 660333 10 Carburetor backing plate (HDI only), Micropore $1.20
15 29242-83 54169 10 Compliance fitting to head, 84-89 $0.30
- 29313-95 660334 10 Filter element mounting (HDI only), Micropore $0.80
Cam Cover / Tappet Gaskets
8 18633-48D 660351 10 Tappet guide (rear), 84-99, Micropore $0.80
9 18634-48C 660358 10 Tappet guide (front), 84-99, Micropore $0.80
10 25225-70B 660359 10 Cam cover, 84-92, silicone bead, Micropore $2.00
- 25225-93 660360 10 Cam cover, 93-99, silicone bead, Micropore $1.60
17 32591-80 660370 10 Point cover (4-hole), 84-99, Syntheseal $0.60
