TRANSMISSION & DRIVETRAIN
                         6-SPEED                                        RevTech 6-Speed Transmission Assemblies

                                                                        6-speed transmission assemblies from RevTech. These transmissions
                                                                        for Softails are available in right and left-side drive, with your
                              Heavy-Duty
                                                                        The left-side drive transmissions are offered with a stock end cover.
                          Performance                                   choice of three different finishes – polished, black, and natural.
                                                                        The LSD transmissions feature all-new 356-T6 cast aluminum cases,
                                                                        with forged trap doors.The RSD transmissions feature a forged
                          Transmission                                  billet aluminum support plate with a hydraulic clutch cylinder and
                                                                        contemporary styling, a large-diameter outside pulley support
                                                                        bearing, and a gold zinc-coated 32-tooth lightened pulley. All these
                                                                        transmissions were subjected to independent dyno durability testing
                 2     680254                                           by a U.S. company in Texas. They were tested for over 120 non-stop
                                                                        hours at extremely high loads, as well as an additional 50,000 shift
                                                                        cycles (10,000 in each gear), and passed easily. The RSD transmissions
                                                                        are designed for custom wide tire builds, and the LSD transmissions
                                                                        fit 90–99 Softails, as well as most custom aftermarket frames.
                                                                        Note: Installation on 94 and newer models will require a speedometer recalibration unit.
                                                                        Both transmission features:
                                                                        • Precision-machined, investment cast steel shift forks.
                                                                        • Fully CNC machined steel shift drum.
                                                                        • Cast 356-T6 aluminum cases.
                                                                        • Forged 6061 aluminum trap door.
                                                                        • 2.93:1 first gear.
                                                                        • 2.20:1 second gear.
                                                                        • 1.60:1 third gear.
                      680253                                            • 1.23:1 fourth gear.
                                                                        • 1.00:1 fifth gear.
                                                                        • 0.88:1 overdrive sixth gear.
                                                                        • 8620H high nickel content chromemoly steel gears.
                                                                        • Extra-quiet gear tooth profiles with helical 5th and 6th gears on
                                                                         the left-side drive transmissions.
                                                                        • Endurance dyno tested by an independent U.S. test lab.
                                                                        RSD Transmission also features:
                                                                        • Unique RSD design.
                                                                        • Large 4.30”-diameter outside bearing support for pulley.
                                                                        • Forged outer support plate with hydraulic clutch.
                                                                        • Gold zinc pulley.
                                                                        • Stylish window cutouts.
                                                                        • Chrome belt guard.
                      680257                                            Left-Side Drive 6-Speed for Softails. Fits Softail models 90-99.
                                                                        680254  Polished                        $1,299.99
                                                                        680253  Black wrinkle                   $1,145.99
                                                                        680252  Natural                         $1,132.99
                                                                        Right-Side Drive 6-Speed for Softails
                                                                        680257  Polished                        $1,699.99
                                                                        680256  Black wrinkle                   $1,699.99
                                                                        680255  Natural                         $1,699.99
                                                                        Replacement parts for RSD transmissions
                                                                        697403  RSD 6 hydraulic piston assembly (incl. bearing   $65.99
                                                                               and seal)
                                                                        689311  RSD chrome belt guard             $57.99
                                                                        M680257



                                                                                  REVTECH
                      680256
                                                                               FIVE YEAR OR
                                                                               50,000 MILE
                                                                               LIMITED
                                                                               WARRANTY
