RevTech 4-Speed Close-Ratio Gear Sets
Matched close-ratio transmission gear sets for Big Twin models from 4-SPEED
36-E84. Each set is complete with the proper gears, shifter clutches,
mainshaft, countershaft, countershaft bearings and all of the
necessary snap rings and thrust washers. The shafts are polished at
the spline and maindrive bushing area and include an O-ring groove 30705
and seals wherever necessary. Gears are honed and finish ground
for precise engagement and maximum strength. The shifter clutches
and shifter dog faces are widened .020" to prevent chipping.
Many of the components of these high-quality kits are compatible
with Original Equipment transmission gears as well as other
aftermarket offerings. Because of the high quality of the materials
and workmanship in these components and their affordable low
price, they are one of the best values available in the performance
transmission market today.
2.44:1 Close-Ratio Sets TRANSMISSION &
30700 2.44:1 Close-Ratio Sets 36-64 $479.99 DRIVELINE
30710 2.44:1 Close-Ratio Sets 65-69 $479.99
30720 2.44:1 Close-Ratio Sets 70-E77 (loose rollers) $479.99
30730 2.44:1 Close-Ratio Sets Late Late 77-E84 (caged $479.99
rollers)
Note: Late 80-early 84 models require Original Equipment countershaft (OEM 35614-80)
2.60:1 Close-Ratio Sets
30705 2.60:1 Close-Ratio Sets 36-64 $479.99 BIG TWIN MAINSHAFT LENGTHS
30715 2.60:1 Close-Ratio Sets 65-69 $479.99 4 speed:
1937-1964: 298mm
30725 2.60:1 Close-Ratio Sets 70-E77 (loose rollers) $479.99 1965-1969: 304mm
30735 2.60:1 Close-Ratio Sets Late 77-E84 (caged $479.99 1970-1985 (chain): 317mm
rollers) 1984-1986 (belt): 349mm
Note: Late 80-early 84 models require Original Equipment countershaft (OEM 35614-80)
M30700 Most 5-in-4 speed: 309mm
Custom Chrome Close-Ratio Third Gear Sets for 5 speed:
4-Speed Big Twin Models 1980-1984: 308mm
Close-ratio 1.35:1 gear sets work great in any Big Twin from 36-86 for 1985-1989: 358mm
more pull in third and improved second and third gear shifting. Sets 1990: 346mm
include mainshaft third gear (23 tooth) and countershaft gear (15 x 1991-2006: 346mm
18 tooth) and retain use of speedometer drive gear. (except 2006 Dyna)
36-E76 (loose rollers) M_TechTIP_SEC11_01
For transmissions up to serial #U-8958.
26217 Mainshaft third gear ONLY $26.99
Late 76-86 (caged rollers)
For transmissions from serial #U-8959 up.
26215 Close-ratio set $87.99 26215
26216 Countershaft gear ONLY $61.99
26217 Mainshaft third gear ONLY $26.99
M26214
Custom Chrome Close-Ratio First Gear Sets for
4-Speed Big Twin Models
The 2.447 close-ratio first gear set is best for FX models; 2.660 ratio
for FL models. Both sets provide a higher first gear and eliminate
second gear clunk, and permit use of a larger engine sprocket for
easier starting. Fit Big Twins from 36-86.
2.447:1 Close-Ratio First Gear Set
Includes mainshaft low and second gear cluster (17 x 20 tooth) and
countershaft low (24-tooth). 25929
25929 Close-ratio set $56.99
26211 Mainshaft low and second gear ONLY $30.99
26209 Countershaft low gear ONLY $24.99
2.660:1 Close-Ratio First Gear Set
Includes mainshaft low and second gear cluster (16 x 20 tooth) and
countershaft low (24-tooth).
26501 Close-ratio set $55.99
26502 Mainshaft low and second gear ONLY $35.99
26503 Countershaft low gear ONLY $27.99
Note: When installed in a 36-58 transmission, you must use a CC #26210 third gear or OEM
35306-59 third gear. 80-86 FX models must use a CC #26213 (21 tooth) second gear (OEM
35751-36).
M25929
