CHASSIS
653105 25577 25246 25252

Weld-In EFI Plate for Custom Chrome Replacement Petcocks
Tanks Chrome-plated duplicates of the stock gas
Convert any custom tank to EFI by welding this valves used from 75-06. Available in three
plate into the base of the tank. Then bolt in an different outlet tube options, straight down,
(OEM 75268-07) Sportster type fuel pump (not left-hand or right-hand for applications at the
included) and you are ready to go. Plate front,rear, or either side of the gas tanks.
dimensions are approximately 8.5" x 5.25" total Complete with a chromed 13/16"nut and
width and length. Minimum width and length nylon mesh filter screen.
of space required for the pump 6.25" x 2.75" 25246 Straight down spigot $17.47
653105 Weld in plate for fuel $59.99 25252 Left-side spigot $17.99
pump
25253 Replacement trim rubber $14.99
260113 25253 12728 12731 Replacement 3-hole Viton $1.50
Rubber Mounts for ‘Flatside’ seal (fits latest design with.
260" fuel tubes)
Gas Tanks
Replacement Filter Screens
Accurate reproductions of the Original
Equipment parts used to mount ‘flatside’ gas 260373 Fits OEM pre-75 $3.99
tanks to 4-speed FX models 85-86, and Softail
models from 84-99. Pack of 6. Replaces OEMs Chrome Petcocks
11447, 5775.
Engineered and designed to eliminate all
25577 Flatside Rubber Mounts, $2.50 internal O-rings. The innercore design insures
price each
against gas leakage while providing
maximum flow.Features a filter screen,
reserve setting, and chrome body.
Mounting Kit for Fat Bob
Tanks 12726 Fits OEM and custom tanks $15.99
thru 74 with internal 3/8"
Hardware kit includes bolts, nuts, washers and 12726 12727 NPT connection
spacers for mounting Fat Bob tanks on 4-speed 12727 3/8" NPT Petcock w/90 $15.99
style Big Twin frames through 84 and most degree outlet. With
customs.
reserve.
260113 Mounting Kit for Fat Bob $6.99
4 75-82 with external 13/16"
Tanks 25245 Fits OEM and custom tanks $14.99
nut connection
CHASSIS with 90°barb
25243
Same fit as CC # 25245 but $17.48
Steel Braided Fuel Line Kit
This kit can be used to replace the fuel
crossover line (between tanks)or fuel feed line
(between petcock and carburetor). Fits all
models with 1/4" I.D.fuel lines. Kits include 16"
25245 25243
braided hose and a pair of chrome end caps.
270565 Steel Braided Fuel Line Kit $15.99
’Wing’ Type Fuel Valve
This classic was used on early Sportsters but it
can be used on any tank with a 3/8 NPT
petcock outlet.
688254 Wing type fuel valve $18.99
Petcock Adaptor
Allows the use of a 22mm petcock in a fuel
tank designed for Delphi fuel injection. Accepts
any petcock that installs using a 22mm nut,
270565 688254 chrome finish and includes o-ring. Sold each.
643240 22mm petcock adaptor $9.99
643240
