CHASSIS
650231 12588 688198

Chrome 3 qt. ‘Barrel’ Style Oil Chrome Oil Tanks for Sportster
Tanks by Santee Models
These Chrome steel oil tanks were styled after Great looking parts that add a bright splash of
the classic ‘Barrel’ tanks on choppers from the chrome to the right side of Sportster models.
60's and 70's. They have a universal mounting Accurate reproductions of the Original
system so they will fit just about anything and Equipment parts, they replace the stock black
are available with or without a spin-on filter. units perfectly. The ideal complement for our
Kits include 3 rubber mounts and tank cap. Oil chrome ignition module and battery covers.
fittings not included.
12588 Fits Sportster models from $159.99
650231 3 qt. round oil tank $362.99 83-93 (repl. OEM 62475-83)
Chrome Wrap-Around Oil Tank 650235 650218 19265 27100 Chrome Oil Tank Cover for XL
by Santee Models 94-03
These 4 qt. oil tanks will fit rigid frames and This chrome oil tank cover set is made of
58-64 swingarm frames with kickstart and steel stamped steel and fits over the oil tank on 94-
primaries, but will NOT fit models with 03 Sportster models without disassembly.
aluminum primaries or 79-84 4-speed 688198 Oil tank cover set, chrome $79.99
transmissions.
fits 94-03 XL models
650235 Center fill oil tank $277.99
Chrome Oil Tanks for Sportster
Chrome Oil Tanks for FL/FX Models
Models and Santee 4-speed Great looking parts that add a bright splash
Swingarm Frames of chrome to the right side of Sportster
models. Accurate reproductions of the
3.5 qt. chrome oil tanks for 65-86 FL and FX 4- Original Equipment parts, they replace the
speed models, that provide easy access to the 28104 27101 stock black units perfectly. The ideal
battery, and bolt to the stock mounts. They complement for our chrome ignition module
will also fit Santee 4-speed swingarm frames. and battery covers.
Kits include oil tank and 2-pc. front mounting
bracket for an easy installation. 688557 Fits Sportster models $139.99
from 97-03
650218 Side fill $394.99 4
Chrome Oil Tank for FXR Models V-Twin Oil Temperature Gauges
A complete chrome oil tank assembly for all CHASSIS 1"-diameter face is easy to read and accurately
FXR models from 82-90 (except 86-up FXR shows oil temperatures between 50° and 350°
Super Glide models). Adds sensational style Fahrenheit.
and simplifies oil draining through the 19265 Fits most custom and OEM $28.99
addition of a second drain hole on the left side-fill tanks from 65-91
rear of the tank. Included with the tank is a except Dyna Glide,
remote drain hose fitting kit which allows it to Sportster and Softail
be drained from the kickstand side through a 632247 25674 models (replaces OEMs
rubber hose which, when not in use, plugs 62635-79T, 62666-87T)
onto a frame mounted dummy fitting which is (black face)
included in the kit. Machine polished and then 19266 Fits Sportster models from $25.99
triple chrome-plated. Replaces OEMs 62406-81, 82-03 and Softail models
62406-86 and 62414-86. from 84-99 (replaces OEMs
28104 Oil tank and remote drain $139.99 62668-87T, 62667-87T)
kit (this tank has no oil (black face)
level" sight" glass) 270046 Fits Softail models from $28.50
00-14 (replaces OEM
62896-00) (white)
Oil Tanks for XL Rigid Frames
This oil tank is for use with rigid Sportster
frames manufactured. Drain plug sold Chrome Oil Tank Dipsticks
separately. Made in USA. Chrome-plated replacements for Original
632247 Oil tank for use w/Paughco $217.99 Equipment dipsticks.
XL rigid frames 78301 78305 27100 With short dipstick for $79.99
Softail models from 84-99
and Sportster models from
Chrome Replacement Oil Tanks 82-99 (repl. OEM 62595-
82A)
Duplicates of the Original Equipment oil talks
finished in brilliant chrome. 27101 With long dipstick for FL $8.99
models from 70-84, FX
78301 Fits 4-speed FL and FX Big $149.99
Twin models from 82-86 models from 71-85, FXR
(repl. OEM 62504-82) models from 82-83, FLT
models from 80-86 and XLCH
78305 Fits 4-speed FL and FX Big $124.99 models from 70-78 (repl.
Twin models from 65-E82 OEM 62625-70A)
(repl. OEM 62504-65A)
Color(s) on photo might be slightly different, please refer to the actual products. All pictures shown are Color(s) on photo might be slightly different, please refer to the actual products. All pictures shown are
for reference only. Please consult your dealer for fitment. for reference only. Please consult your dealer for fitment.

www.customchrome.com 4.54 4.55 *Prices shown are suggested retail prices only. Actual retail prices are determined by each dealer and may vary. Please see Cautionary Information in back of catalog.
All parts are sold each unless otherwise noted. Retail prices may reflect an each quantity.
