Page 277 - Custom Chrome Catalog

CHASSIS
688695 160636 160638

Kickstand Wedge Kit for Dual Disc 41 mm Front End
Touring Models Assemblies for FXWG Models
Allows the use of the stock kickstand when from 80-83
the bike is lowered, without excess lean. All Our complete dual disc front end assemblies
mounting hardware is included.
come complete with chrome upper and lower
688695 Kickstand wedge FLT 84- $39.99 triple trees,hard chromed fork tubes, springs,
08 and all internal components. With polished
aluminum lower legs, these front ends are a
direct replacement for FXWG models from 80-
83 and can be fitted to any Big Twin from 49-
99 when 77-83-style dual disc calipers are
Kickstand wedge used. The chrome triple trees feature 3 1/2"
170140 riser spacing, a central headlight mounting
Fits 84-99 Softail models.
hole and an identical 3° rake angle as the
170140 Kickstand wedge Big $15.99 factory originals.
Twins
160635 3 1/2" under stock length $695.99
160636 Stock length $669.99
160637 2" over stock length $659.99
Installation Kit
161010 For FX Softail models $37.99
ONLY (includes bearings,
dust shields, top nut and
acorn crown nut with
lock tab)
Kickstand Springs Single Disc 41 mm Front Fork
688185 688186 160639
High-quality replacement kickstand springs. Assemblies for Softail Models
Sold each.
from 84-99
688185 Chrome, Fits 91-01 Dyna $6.99
models (replaces OEM Our single disc front end assemblies come
50057-91) 4 complete with chrome upper and lower triple
trees, hard chrome stock-length fork
688186 Black, Fits 99-06 Touring $4.99 tubes,springs, dampeners and all internal
models (replaces OEM components.Perfect for scratch builders or
50112-99) chrome conversions on late Softail models.
688187 Black, Fits FXST 85-06, FXR $5.45 CHASSIS Direct replacement for Original Equipment
91-94, FLT 91-98 and XL parts, that accept stock headlights, risers, fork
86-09 (replaces OEM trim, fenders and axles. Available in both
50005-85) styles with a choice of chrome or polished
688188 Black, Fits 37-84 FL, 84 $3.99 aluminum lower legs.
FXST, 80-90 FLT, 52-83 XL For FX Softail Models from 84-99
and K-models (replaces 688187 688188 160638 Polished lower legs $695.99
OEM 50011-30A)
For FL Softail Models from 86-99
688184 Black, Fits 07-Up Softail $4.99
and Touring models 160639 Polished lower legs $699.99
(replaces OEM 49725-
07A)

Kickstand Bumper for Softail 688640
Replacement kickstand bumper fits Softail
models 89-06. Also used on many one-piece
fuel tanks on FX, FXE and XL 73-E84. Sold each.
688640 Replaces OEM 62123-07, $1.69
each
