Easy Starter Kits for Big Twin Models 17664
Improves starting on high-compression big inch engines through an
improved starter-to-clutch basket gear ratio. Complete kits include a
clutch basket for Big Twin models with a 66-tooth starter ring and a 9-
tooth starter pinion gear.
17664 Complete kit for Big Twin models from 94-97 $243.99
17665 Complete kit for Big Twin models from 98-06 $243.99
(except 06 Dyna)

Starter Ring Gear
Replacement ring gear for the clutch drum. Fits electric start Big Twins
(except diaphragm clutch) from 65-E84.
17402 Replaces OEM 33163-65B $58.99

Replacement Starter Jackshaft Kits
Complete jackshaft kits include starter shaft, coupling, pinion gear,
clips, spring, locktab, washers and screws.
28380 10-tooth for Big Twins from 94-06 (except 06 Dyna) $89.99 17402
628370 9-tooth for 94-06 Big Twins from when using a 66- $71.37
tooth starter ring gear on 94-06 models
Replacement Starter Motor Parts
Listed below in OEM part number order. All parts are sold each.
28381 9-tooth for Big Twins from 89-93 $89.99
28386 Pinion gear for Big Twins from 89-93 (repl. OEM $23.99
31342-90)
28382 Coupling for Big Twins from 89-93 (repl. OEM $9.99
31548-90)
28384 Extension shaft for Big Twins from 89-93 (repl. $25.99
OEM 33127-90)
688565 Starter shaft bushing 89-93 Big Twins OEM 33445- $6.99
89
688564 Starter shaft bushing 94-06 Big Twins (exc. 06 $7.49 28380
Dyna)OEM 33445-94A
92200 Starter shaft bushing for Big Twins from 89-93 $5.99
(repl.OEM 33445-89)
28383 Pinion coupling for Big Twins from 89-93 (repl. $15.99
OEM 60647-90)

Starter Shaft for Big Twins
28616
28616 Starter shaft ONLY for 4-speed FL chain drive $24.99
models from 70-82, and 4-speed FX chain drive
models from 71-85 (replaces OEM 31482-70)

Starter Motor Housings LIGHTING,INSTRUMENTS & ELECTRICAL
Replacement starter motor housings that duplicate the Original
Equipment parts which commonly have the mounting ears broken off.
Needle bearing not included.
09782 Fits 4-speed Big Twin models with Prestolite motor $44.99
65-E79(repl. OEM 31465-65) 1/4-20 threads (use CC 09782
#28605 bolts)
09779 Fits 4-speed Big Twin models with Hitachi motor $44.99
73-E79 (repl. OEM 31572-73) 10-24 threads (use CC
#28625 bolts)
09778 Starter housing bearing (replaces OEM 9062) sold $9.99
each
