                     RevTech Gen 4 – 115 & 125
                     Motors Parts List Charts                 A


                                                                                                E


                                                       C                       D











                      Chart A                                          Chart C
                      Piston With Rings For RevTech 125” Motors. Sold each.  Cylinder for RevTech 125” Motors. Sold each.
                      684678  Front Piston 4-1/4” bore, standard size with   $170.99  684704  125” Natural cylinder 4-1/4” bore, front.  $263.99
                             rings, wrist pin & clips                  684705  125” Natural cylinder 4-1/4” bore, rear.  $263.99
                      684679  Front Piston 4-1/4” bore, +.005” oversize with   $170.99  684706  125” Black cylinder 4-1/4” bore, front.  $292.99
                             rings, wrist pin & clips                  684707  125” Black cylinder 4-1/4” bore, rear.  $292.99
                      684680  Front Piston 4-1/4” bore, +.010” oversize with   $170.99  684708  125” Polish cylinder 4-1/4” bore, front.  $381.99
                             rings, wrist pin & clips
                                                                       684709  125” Polish cylinder 4-1/4” bore, rear.  $381.99
                      684681  Front Piston 4-1/4” bore, +.020” oversize with   $170.99
                             rings, wrist pin & clips                  Cylinder for RevTech 115” Motors. Sold each.
                                                                       684710  115” Natural cylinder 4-1/8” bore, front.  $263.99
                      689192  Rear Piston  4-1/4” bore, standard size with   $170.99
                             rings, wrist pin & clips                  684711  115” Natural cylinder 4-1/8” bore, rear.  $263.99
                      689193  Rear Piston  4-1/4” bore, +.005” oversize with   $170.99  684712  115” Black cylinder 4-1/8” bore, front.  $292.99
                             rings, wrist pin & clips                  684713  115” Black cylinder 4-1/8” bore, rear.  $292.99
                      689194  Rear Piston  4-1/4” bore, +.010” oversize with   $170.99  684714  115” Polish cylinder 4-1/8” bore, front.  $381.99
                             rings, wrist pin & clips                  684715  115” Polish cylinder 4-1/8” bore, rear.  $381.99
                      689195  Rear Piston  4-1/4” bore, +.020” oversize with   $170.99  Chart D
                             rings, wrist pin & clips                  Cylinder Heads for RevTech 125” & 115”. (Valve guides &
                      684694  Retaining clip, wrist pin. Sold in a pair  $2.49  valve seats installed). Sold each.
                      Piston With Rings For RevTech 115” Motors. Sold each.  684716  Natural front head for Gen 4 motors.  $263.99
                      684687  Front Piston 4-1/8” bore, standard size with   $170.99  684717  Natural rear head for Gen 4 motors.  $263.99
                             rings, wrist pin & clips                  684718  Black front head for Gen 4 motors.  $292.99
                      684688  Front Piston 4-1/8” bore, +.005” oversize with   $170.99  684719  Black rear head for Gen 4 motors.  $292.99
                             rings, wrist pin & clips                  684720  Polish front head for Gen 4 motors.  $381.99
                      684689  Front Piston 4-1/8” bore, +.010” oversize with   $170.99  684721  Polish rear head for Gen 4 motors.  $381.99
                             rings, wrist pin & clips
                      684690  Front Piston 4-1/8” bore, +.020” oversize with   $170.99  Chart E
                             rings, wrist pin & clips                  Push rods for RevTech 125” & 115”. Sold each.
                      689196  Rear Piston 4-1/8” bore, standard size with   $170.99  684722  Pushrod, rear exhaust.  $7.29
                             rings, wrist pin & clips                  684723  Pushrod, rear intake.               $7.29
                      689197  Rear Piston 4-1/8” bore, +.005” oversize with   $170.99  684724  Pushrod, front exhaust.  $7.29
                             rings, wrist pin & clips                  684725  Pushrod, front intake.              $7.29
                      689198  Rear Piston 4-1/8” bore, +.010” oversize with   $170.99  Gaskets and Seals
                             rings, wrist pin & clips                  684682  Complete engine gasket, seal & o-ring kit for   $110.99
                      689199  Rear Piston 4-1/8” bore, +.020” oversize with   $170.99  RevTech 125” engines
                             rings, wrist pin & clips                  684683  Complete engine gasket, seal & o-ring kit for   $113.99
                      684694  Retaining clip, wrist pin. Sold in a pair  $2.49  RevTech 115” engines
                      Chart B                                          684684  Top End gasket, seal  & o-ring kit for RevTech   $97.99
                      Ring Set For RevTech 125” Motors. Sold in a set for 1 piston.  125” engines
                      684695  4-1/4” bore piston ring set, standard size.  $37.99  684685  Top End gasket, seal  & o-ring kit for RevTech   $100.99
                      684696  4-1/4” bore piston ring set, +.005”oversize.  $37.99  115” engines
                 7    684697  4-1/4” bore piston ring set, +.010” oversize.  $37.99
                             4-1/4” bore piston ring set, +.020” oversize.
                                                                $37.99
                      684698
                      Ring Set For RevTech 115” Motors. Sold in a set for 1 piston.
                      684700  4-1/8” bore piston ring set, standard size.  $37.99
                      684701  4-1/8” bore piston ring set, +.005” oversize.  $37.99
                      684702  4-1/8” bore piston ring set, +.010” oversize.  $37.99
                      684703  4-1/8” bore piston ring set, +.020” oversize.  $37.99
