Page 242 - Custom Chrome Catalog

CHASSIS
46188 25568
Stretched Flatside Fat Bob
Tanks for Softail Models
Stretched tanks are one of the hottest custom
bike trends. We start with our best selling 5
gallon tanks and weld on custom formed steel
extensions. The extensions add over two
inches to the length of the tank and create a
smooth flowing look by filling the void
between the seat and where the tank
normally ends. Manufactured of heavy gauge
steel on new tooling,each tank is hand
inspected and pressure tested to ensure
quality and a perfect fit. Designed for use with 15696 25551
a stock dash, tank panel, late model (13/16"
thread) petcock and most standard width
seats. Available with bungs for 82-95 screw-in
gas caps. Fit Softail models from 84-99 and
most frames with mounts for flatside tanks.
Gas caps must be purchased separately.
46188 5 gallon Screw-in style $251.99
cap, stretched tank
Note: Stretched portion of tank does not hold fuel.
Some wide or touring seats may require modification.
All fuel tanks must be test fitted, pressure tested, and
pre-sealed before painting. Tanks require finish body
work.
Flatside Gas Tanks with 15294 43002001
Screw-Type Gas Caps
Designed to accept 82-95 screw in caps. Each
tank is formed on all-new tooling to ensure
quality. Tanks are designed to work with stock
and most aftermarket frames with flatside 4 15696 2" stretch with single
brackets and single large diameter
instruments, dashes, trim panels and 13/16"
petcocks. Fit Softail models from 84-99 and
most aftermarket frames with mounts for CHASSIS
flatside tanks.
Gas caps must be purchased separately.
15298 5 gallon $205.99
15294 6 gallon $184.99
Note: Due to the slightly different contour of the 6-
gallon tanks, flexible steel, leather or plastic tank
panels should be used. All fuel tanks must be test
fitted, pressure tested,and pre-sealed before painting.
Tanks shown painted for illustration purpose only,
tanks require finish body work.
Fat Bob Gas Tanks
Tanks are designed with accurate, precision-
placed mounting plates and stud bosses. For
increased durability, lowtemperature welding
is used throughout the tank. Accepts either
the dash for Low Rider models or the Fat Bob
dash for FL and FXWG models. Features late
13/16" external-thread fuel valve connections
for Original Equipment style gas valves (CC #'s
25245, 25243) or high volume versions.
Available to accept either pre-1982 cam-style
gas caps or later model screwin style gas caps.
They are shipped with a dash spacer kit to
accommodate the increased height. Fit all
Original Equipment and aftermarket 4-speed
Big Twin frames thru 84 (except FXST models).
Tanks with Cam-Style Bungs
15289 3.5 gallon $159.99
25549 5.0 gallon $152.99
Tanks with Screw-Style Bungs
15295 3.5 gallon $169.99
15296 5.0 gallon $199.99
Note: Fuel tanks, must be pressure tested and sealed
before painting to protect the final finish and prevent
internal rust.
Color(s) on photo might be slightly different, please refer to the actual products. All pictures shown are
for reference only. Please consult your dealer for fitment. for reference only. Please consult your dealer for fitment.
www.customchrome.com 4.40 4.41 *Prices shown are suggested retail prices only. Actual retail prices are determined by each dealer and may vary. Please see Cautionary Information in back of catalog.
All parts are sold each unless otherwise noted. Retail prices may reflect an each quantity.
3.5 Gallon Hand Shift Gas
Tanks
Two versions of the obsolete hand shift style
3.5 gallon gas tank sets. Accurate placement
of the shifter gate lugs and shut-off rod hole
centers ensures trouble-free service. Available
in two versions. One is a totally accurate
reproduction of the original, rod-style gas
shut-off equipped tank used from 48-65. The
other is based on the same tank, but
eliminates the early style gas shutoff rod
system and replaces it with the tank bottom
fitting for the late 13/16" external-thread
petcock. Both tanks accept the correct cam-
style gas caps and are designed to accept the
stock shifter guide. (Sold separately.)
25568 Original style with rod $219.99
shut-off (shown)
25569 Updated style for 75-07 $219.99
petcock
Custom Smooth-Top Gas
Tanks for FXR Models
Our 2" stretch tanks are new stampings
rather than using welded tips to achieve
stretch. They come with flush-mount locking
gas cap (included). Single cap tanks have inlet
43003001 offset to the right side. Tanks fit all models
from 82-99 and have a 4.0 gallon capacity.
Models with stock turn signals mounted to
the top triple tree must relocate them to
avoid contact with the tank.
$442.99
flush locking cap
Fat Bob Gas Tank for FXR
Models
Classic Fat Bob look for all FXR models from
82-99. It has the appearance of split tanks,but
is really a one piece welded tank with twin
screw type filler necks,and 13/16" external
thread gas valve fitting. Bolts directly to the
stock mounts and accepts all FL-style dash
15296 43004001 assemblies (except Cateye) when the
appropriate dash base is used. Included with
each tank is a superflex speedo cable and a
chrome tank divider panel (dash and speedo
sold separately). The tanks are even equipped
with internal emission control system
connections, for use on vehicles WITH fuel
tank emission devices (i.e., California models).
25551 4-gallon Fat Bob gas tank $274.99
for FXR models
Note: CC #25551 tanks require removal of solder from
vent tube prior to installation on vehicle when
connecting fuel tank emissions control devices.
Stretched Custom Gas Tank
Manufactured from heavy gauge steel on
new tooling. This one-piece tank is perfect for
a variety of custom applications. Each tank
comes with a gas cap and is factory pressure
tested and corrosion protected and sealed.
The tank must be fitted to frame before
painting.
For Carburated Models; Primer Gray
43002001 4.7 gallons, L-28.5", W- $259.99
14.5", H-9"
43003001 4.5 gallons, L-23.62", W- $259.99
14.57", H-9.45"
43004001 4.7 gallons, L-22.64", W- $259.99
15.16", H-9.45"
