Disc Brake Rotors 25636 25637
A wide selection of zinc-alloy and stainless steel
disc brake rotors to fit most Harley-Davidson
models from 72-99. The stainless steel rotors are
surface induction hardened with a 12-14%
chrome content for superior wear characteristics
on #420 steel plate. Each rotor is precision-
ground for trueness, and available in vented and
non-vented versions which are interchangeable
with Original Equipment disc rotors.
Note: Zinc rotors are not compatible with sintered metal
pads.
Fit Sportster and FX models with
single disc from 74-77 (replaces OEM
41807-74)
11 1/2"-diameter, countersunk mounting holes,
use stock hardware or CC #36228 chrome-plated
screw set.
25636 Vented zinc $44.99
25634 24628
24626 Vented stainless steel $95.99
Fit all FX, FXR and Sportster models
77-83 with dual disc front brake
(replaces OEM 44137-77A)
10"-diameter, countersunk mounting holes, use
stock mounting hardware or CC #25193 chrome-
plated screw set.
25637 Vented zinc $39.99
24627 Vented stainless steel $81.99
Fit all single or dual disc front brake
applications from 84-99 (replaces OEM
44136-84A)
11 1/2"-diameter, counterbored mounting holes,
use stock mounting hardware or CC #’s 36229 or
36231 chrome-plated screw sets (two sets CHASSIS
required for dual disc applications).
25634 Vented zinc $43.99 24625
24624 Vented stainless steel $95.99
Fit the front of FL models from 72-84
and the rear of FL or FX models from
73-80 (replaces OEMs 41806-72B,
41813-79)
10"-diameter, counterbored mounting holes,
use stock hardware or CC #’s 36227 or 36226
chrome-plated hardware kits.
25638 Vented zinc $43.99
24628 Vented stainless steel $81.99
Fit the rear of all FX and Softail
models from 81-91, the rear of all
Sportster models from 79-91, and FXR
models from 82-91 (replaces OEM
41791-79A)
11 1/2"-diameter, tapered countersunk mounting
holes, use stock hardware or CC #36230 chrome-
plated screw set.
25633 Vented zinc $45.99
24625 Vented stainless steel $95.99
Fit the rear of all Sportster and Big
Twin models (except FLT, FLHT, FLHS
and Road King models) from 92-99
(replaces OEM 41789-92)
11 1/2"-diameter, counterbored mounting holes,
uses stock hardware or CC #32573 chrome-plated
screw set.
24630 Vented stainless steel $95.99
