P. 378
CHASSIS
Dual Flange Wheel Assemblies
Polished stainless steel spokes are laced to chrome rims and hubs. The 16"
wheel assemblies feature our European-manufactured chrome 16" rims.
These hubs feature thicker spoke flanges, and rotor flanges held to .001"
runout. All hubs accept any stock sprocket/rotor or rotor/rotor combination
for greater flexibility when building custom wheel combinations. They
include all internal spacers, seals and washers, and bearing end play is set at
the factory. Wheel assemblies will bolt-on to most models from 73-85.
Note: Wheels fit the rear of most models from 86-99 when installed with a CC #19722
spacer (OEM 40932-81) between the belt pulley or sprocket and the hub.
Wheels with 7/16" and 3/8” Flange Holes
18687 16" x 3.00" with stainless steel spokes $379.99
Wheels with 5/16" Both Sides Flange Holes
19675 16" x 3.00" with stainless steel spokes $379.99
18695 21" x 2.15" with stainless steel spokes $389.99
Front Axle Spacer for FXWG Models
Replacement right or left axle spacers for FXWG models. May also be used
when fitting other wheels (such as CC #’s 19687 or 19694) to late model front
ends.Sold in packs of 5.
19696 80-83 left spacer (repl. OEM 41594-73) $3.60
19697 83 right spacer (repl. OEM 41607-83) $3.50
Chrome Dual Flange Wheel Hubs
Complete chrome hub assemblies for the front or rear of most Harley-Davidson
models from 73-99. 7/16" or 5/16" holes in both flanges, all internal components
and bearing preload set at the factory.
19678 Front or rear hub with 7/16" holes in both flanges for $159.99
models from 73-85 (repl. OEM 43540-73A)
609810 Rear hub with 7/16“ Pulley /Sprocket side flange holes $169.99
& 3/8“ Brake Rotor side flange holes for models from
86-99 (repl. OEM 40976-86)
19776 Rear hub with 7/16" Pulley /Sprocket side flange holes $164.99
& 7/16" Brake Rotor side flange holes for models from
86-99 $189.99
4 19800 43663-80A) $39.99
Front hub with 5/16" holes in both flanges (repl. OEM
Rebuild kit (includes bearings, cones, seals, spacers,
19718
washers and retaining rings)
26051 Bearing and cone (repl. OEM 9052) $9.99
19554
26138 Bearing only $7.99
26137 Cone only $5.99
19682 Outer bearing spacers (repl. OEM 41196-73) sold in $7.99
pairs
54331 Rubber oil seals (repl. OEM 47519-58) pack of 10 $1.30
54207 Rubber oil seal (repl. OEM 47519-83A) pack of 10 $1.80
Belt Pulley and Sprocket Spacer
This part was used on many Big Twin models from 80-85. It was most
commonly used on belt drive models to achieve the proper spacing of the
rear belt pulley to the wheel. This spacer is required for use on our rear
wheels when used in many different applications. Fits Big Twin and Sportster
models.
19722 Replaces OEM 40932-81 $10.49
M18687
Chrome Rear Hub Assembly for Big Twins from
67-72
Complete wheel hub assembly includes the chrome hub and all of its internal
components with properly spaced bearings. The hub fits the front or rear
wheel of all FL models from 67-72 and the rear of FX models from 71-72.
19554 Complete hub assembly (repl. OEM 43540-67A) $191.99
19559 Bearing spacer (repl. OEM 43549-67) $4.49
19560 Bearing locknut (repl. OEM 43542-67) $8.99
19562 Hub spacer (repl. OEM 41196-55) $3.99
54324 Rubber oil seal (repl. OEM 41210-55) Sold in packs $1.30
of 10
26133 Hub bearing (repl. OEM 43577-67) $35.99
M18555
*Prices shown are suggested retail prices only. Actual retail prices are determined by each dealer and may vary.
4.126 All parts are sold each unless otherwise noted. Retail prices may reflect an each quantity. Please see Cautionary Information in back of catalog.
