P. 379
Front Wheel Assemblies for Sportster and FX
Models from 74-77
A selection of stock replacement and custom front wheels for all 74-77
Sportster and FX models (except 77 FXS and XLCR) with single disc narrow
glide front ends. Available with polished stainless steel spokes laced to a
chrome hub and a 19" or 21" Drop Center rim with rolled edge. Each wheel
assembly is complete with axle spacer, seals and bearings with their preload
set at the factory.
18552 19" x 2.50" with stainless steel spokes $399.99
18553 21" x 2.15" with stainless steel spokes $399.99
Chrome Front Hub Assembly for Models from 74-77
A complete assembly including the chrome hub and all of its internal
components with properly spaced bearings. Hub fits the front wheel on
Sportster and FX models from 74-77 (except 77 FXS and XLCR).
19551 Complete hub assembly (repl. OEM 43600-74) $174.99
19583 2.166" center bearing spacer (repl. OEM 43745-73) $4.99
19594 Left bearing spacer (repl. OEM 43548-74) $4.99
19693 Rebuild kit (includes bearings, cones, seals, and left- $31.99
hand spacer)
54332 Steel oil seal (repl. OEM 47519-72) pack of 10 $1.10
26051 Bearing and cone (repl. OEM 9052) $9.99
M18552
Wheels with Timken-Style Star Hubs for 36-66
Big Twins
A wide selection of stock replacement and custom wheels with polished
stainless steel spokes laced to our patented Star Hub with Timken-style
bearings (CC #64012). Bearing preloads are set at the factory. These
complete wheel assemblies fit the front or rear of most Big Twin models
from 36-66 when the appropriate Custom Chrome Axle and Hardware kit
is used. The stock brake axle sleeve for the appropriate application is also
required. Though the Axle Kits will work with Original Equipment Star Hubs,
the Original Equipment axles will not work with Custom Chrome Wheel
Assemblies with Star Hubs.
Complete Wheel Assemblies
18547 16" x 3.00" with stainless steel spokes $379.99
18541 21" x 2.15" with stainless steel spokes $399.99
Star Hub with Timken-Style Bearings CHASSIS
64012 Complete Star Hub assembly $179.99
Axle and Hardware Kits
64057 Front for models from 36-48 $46.99
64058 Front for models from 49-66 $40.99
64066 Rear for models from 36-57 $51.99
64067 Rear for models from 58-66 $43.93
Replacement Spokes
08019 16" spoke set. Chrome $49.99 U.S. Patent
08219 16" spoke set. Stainless steel $109.99 #4,880,280
08023 21" spoke set. Chrome $45.99
08223 21" spoke set. Stainless steel $139.99 64012
08025 19" spoke set Chrome $42.99
08225 19" spoke set Stainless steel $141.99
*New style lacing pattern.
Replacement Parts
64005 Bearing only (pair) $15.99
23999 Steel oil seal (1.625" O.D.) pair $3.99
64007 Chrome axle spacer (sold each) $5.99
64008 Retaining ring (pair) $2.99
19620 Outer cover without hole for zerk fitting (repl. OEM $8.99
43566-35TA)
19568 Hub cover screw/lockwasher kit (pack of 5) $3.99
M18547
