P. 499

Flathead Big Twins                             Gaskets for 74" and 80"


                                                                              Flatheads from 37-48
                                                                              These gaskets and seals fit U, UL
                        2                                                     and ULH Big Twin models.
                                                              2
                                           7
                                                                                      11
                                                                                                     10
                                                   1             6
                               1
                                                                                    16                 12
                                           9
                                                             8
                                                                                              15
                                        4
                                                                                                          14
                                                            3                      13
                         5

                       Gaskets for Flathead Big Twins 37-48
                        No.   OEM#   Motor   Qty Description                                                    Each Price
                                     Factory
                       Cylinder Gaskets
                         1   16774-21  54107  10  Cylinder base, 37-48                                              $0.40
                       Rocker Box Gaskets
                         -   18198-38  54279  10  Valve guide, 37-48                                                $0.25
                         -   18259-39  54280  10  Lower valve cover, 37-48                                          $0.85
                         -   18260-29  54284  10  Valve Spring Cover Seal, 37-48                                    $0.50
                         -   18630-26  54281  10  Valve cover and guide, 37-48                                      $1.50
                       Cam Cover Gasket
                         4   25227-37  54277  10  Gear case cover, 37-48                                            $1.00
                       Primary Gaskets
                        13   60540-36  12046  10  Primary cover (cork), 37-48                                       $5.30
                        14   60565-36  12048  10  Clutch cover (cork), 37-48                                        $3.90
                        15   60567-36  12050  10  Inspection cover (cork), 37-48                                    $0.40
                       Transmission Gaskets
                         -   25811-11  54132  10  Neutral switch, 37-48                                             $0.40
                        10   33295-36  660371  10  Transmission side cover, 37-48, Syntheseal                       $1.40
                         -   34459-26  54183  10  Washer, shift shaft, 37-48                                        $0.70
                        11   34824-36  660400  10  Ratchet top, 37-48, Syntheseal                                   $1.00
                         -   35231-36  25320  10  Mainshaft cork washer, 37-48                                      $1.00
                        12   36025-36  660517  10  Countershaft end cap, 36-47, Syntheseal                          $0.45
                         -   62702-52  54223  10  Drain plug, 37-48                                                 $1.50
                        16   67141-36  54232  10  Speedometer drive to case, 37-48                                  $0.50
                       Oil Pump Gaskets
                         3   24921-37  54278  10  Oil pump relief pipe, 37-48                                       $0.45
                         6   26246-37  54134  10  Oil pump base and cover, 37-48                                    $0.40
                       Miscellaneous Gaskets
                         2   18631-30  54275  10  Tappet guide, front and rear, 37-48                               $0.40
                         -   27376-28  54155  10  Float bowl nut washer                                             $1.60
                         7   27410-39  54162  10  Intake manifold                                                   $0.80
                         -   30138-30  54240  10  Generator end cover, 37-48                                        $0.30
                         8   30143-58  660511  10  Generator mount, 37-48, Synthseal                                $0.45
                         9   32522-37  25313  10  Distributor base, 37-48                                           $0.75
                       Seals for Flathead Big Twins 37-48
                         -   18245-39  54283  10  Pushrod cover cork, upper, 37-48                                  $0.35
                         -   18257-39  54282  10  Pushrod cover cork, lower, 37-48                                  $0.70
                         -   33076-37  19077  10  Kickstart shaft, 36-47 (square type seal)                         $0.60
                         -   34036-36  54064  10  Shifter cam, 37-48                                                $1.20
                         -   35230-39  25103  EA  Mainshaft, 41-48, (double lip)                                    $2.49
                         -   37337-36  54205  10  Clutch pushrod cork, 37-48                                        $0.45    SERVICE

                      Motor Factory Transmission Gasket Kit and Parts for Early Models
                      Complete kit includes gaskets, seals and washers.
                       No.  Description                               Each Price
                                                                                 19493
                       19493  Complete kit for 45" W, WL, WLA, G and ServiCar
                            models from 40-73 (repl. OEM 33030-41)        $24.99
                       54191  Top cover gasket (repl. OEM 34825-41) pack of 10    $0.65
                       54192  Side cover gasket (repl. OEM 34826-41) pack of 10    $0.55
                       54064  Shifter cam shaft seal (repl. OEM 34036-36) pack of   $1.20
                            10
                       54183  Shifter shaft washer (repl. OEM 34459-26) pack of   $0.70
                            10
                       54193  Case cover seal (repl. OEM 34831-39) pack of 5    $0.80
                       54068  Clutch gear seal (repl. OEM 37465-41) pack of 5    $3.10
                      M19493                            www.customchrome.com                                        6.29
